The
Reset Memory 237 parameter to be selected in the PARA menu branch of the
operating unit enables purposeful resetting of the individual average and peak values.
The peak value and the average value with the values stored in the period are over-
written with the parameter value zero.
Operation mode Function
0 - No deleting Values of actual value memory remain unchanged.
1 -
Peak Value Long Term
Ixt
Reset
Peak Value Long-Term Ixt 231.
2 -
Peak Value Short Term
Ixt
Reset
Peak Value Short-Term Ixt 232.
3 - Peak Value Vdc
Reset
Peak Value Vdc 287.
4 - Average Value Vdc
Delete
Average Value Vdc. 288.
5 - Peak Value Tc
Reset
Peak Value Heat Sink Temp. 289.
6 - Average Value Tc
Delete
Average Value Heat Sink Temp. 290.
7 - Peak Value Ti
Reset
Peak Value Inside Temperature 291.
8 - Average Value Ti
Delete
Average Value Inside Temperature 292.
9 - Peak value Irms
Reset
Peak Value Irms 293.
10 - Average value Irms
Delete
Average Value Irms 294.
11 - Peak Value Pactive pos.
Reset
Peak Value Active Power pos. 295.
12 - Peak Value Pactive neg.
Reset
Peak Value Active Power neg. 296.
13 - Average Value Pactive
Delete
Average Value Active Power 297.
16 - Energy, positive
Reset parameter
Energy, positive 301.
17 - Energy, negative
Reset parameter
Energy, negative 302.
100 - All Peak Values Reset all peak values stored.
101 - All Average Values Delete average values and stored values.
102 - All Values Delete the entire actual value memory.
18.4 Actual Values of the System
The calculation of the actual values of the system is based on the parameterized sys-
tem data. Specific to the application, the parameters are calculated from the factors,
electrical variables and the controls. The correct display of the actual values is a func-
tion of the data of the system to be parameterized.
18.4.1 Actual Value System
The drive can be monitored via the actual value Actual Value System 242.
The
Actual Frequency 241 to be monitored is multiplied by the Factor Actual Value
System
389 and can be read out via the parameter Actual Value System 242, i.e.
Actual Frequency 241 x Factor Actual Value System 389 = Actual Value System
242.
Actual Value System
No. Description Function
242 Actual Value System Calculated frequency of drive
