7.5 Set-up via the Communication Interface
Parameter-setting and commissioning of the frequency inverter via one of the optional
communication interfaces include the plausibility check and the parameter identifica-
tion functions. The parameters can be adjusted by qualified users. The parameter
selection during the guided commissioning procedure includes the basic parameters.
These are based on standard applications of the corresponding configuration and are
therefore useful for commissioning.
Caution! Parameter settings may only be changed by qualified staff. Before starting
the commissioning process, read the documentation carefully and comply
with the safety instructions.
The parameter
SETUP Selection 796 defines the function which is carried out directly
after the selection (if controller release signal is present at digital input S1IND). The
operation modes include functions which are also carried out automatically one after
the other during the guided commissioning procedure.
SETUP Selection 796 Function
0 - Clear Status The auto set-up routine does not perform a function
1 - Continue
The warning message is acknowledged and the auto set-up
routine is continued.
2 - Abort
The auto set-up routine is stopped and a RESET of the fre-
quency inverter is performed.
10 -
Complete Setup,
DS0
The auto set-up routine is performed in data set 0 and the
parameter values are stored in all of the four data sets iden-
tically.
11 -
Complete Setup,
DS1
The parameter values of the auto set-up are stored in data
set 1.
12 -
Complete Setup,
DS2
The parameter values of the auto set-up are stored in data
set 2.
13 -
Complete Setup,
DS3
The parameter values of the auto set-up are stored in data
set 3.
14 -
Complete Setup,
DS4
The parameter values of the auto set-up are stored in data
set 4.
20 -
Check Machine
Data, DS0
The auto set-up routine checks the rated motor parameters
in the four data sets.
21 -
Check Machine
Data, DS1
The rated motor parameters in data set 1 are checked for
plausibility.
22 -
Check Machine
Data, DS2
The rated motor parameters in data set 2 are checked for
plausibility.
23 -
Check Machine
Data, DS3
The rated motor parameters in data set 3 are checked for
plausibility.
24 -
Check Machine
Data, DS4
The rated motor parameters in data set 4 are checked for
plausibility.
30 -
Calculation and
Para-Ident., DS0
The auto set-up routine determines extended motor data via
the parameter identification feature, calculates dependent
parameters and stores the parameter values in all of the four
data sets identically.
31 -
Calculation and
Para-Ident., DS1
Further motor data are measured, dependent parameters are
calculated and the parameter values are saved in data set 1.
32 -
Calculation and
Para-Ident., DS2
Further motor data are measured, dependent parameters are
calculated and the parameter values are saved in data set 2.
33 -
Calculation and
Para-Ident., DS3
Further motor data are measured, dependent parameters are
calculated and the parameter values are saved in data set 3.
34 -
Calculation and
Para-Ident., DS4
Further motor data are measured, dependent parameters are
calculated and the parameter values are saved in data set 4.
