18.2 Actual Values of the Machine
The frequency inverter controls the behavior of the machine in the various operating
points. As a function of the configuration selected and the expansion cards installed,
control variables and further actual value parameters of the machine can be dis-
played.
Actual Values of the Machine
No. Description Function
210 Stator Frequency
The output frequency (motor frequency) of the
frequency inverter.
211 R.m.s Current
Calculated effective output current (motor cur-
rent) of the frequency inverter.
212 Output Voltage
Calculated R.m.s. figure of the phase-to-phase
voltage (motor voltage) of the frequency inverter
213 Active Power
Active power calculated from the voltage, the
current and the control variables.
214 Active Current
Active current calculated from the rated motor
parameters, the control variables and the current
215 Isd
Current component of the field-orientated control
forming the magnetic flux.
216 Isq
Torque-forming current component of field-
orientated control.
217 Encoder 1 Frequency
Calculated from the data on encoder 1, the
No.
of Pole Pairs
373 and the encoder signal.
218 Encoder 1 Speed Calculation from encoder 1 frequency.
221 Slip Frequency
Difference from the synchronous frequency cal-
culated from the rated motor parameters, the
control variables and the current.
224 Torque
Torque at the current output frequency calcu-
lated from the voltage, the current and the con-
trol variables.
225 Rotor Flux
Current magnetic flux relative to the rated motor
parameters.
226 Winding Temperature
Measured temperature of the motor winding
according to O
peration Mode 465 for tempera-
ture adjustment.
227 Act. Rotor Time Constant
Time constant calculated for the operating point
of the machine from the rated motor parame-
ters, the rated and control variables.
235 Flux-Forming Voltage
Voltage component of the field-orientated control
forming the magnetic flux.
236 Torque-Forming Voltage
Voltage component of the field-orientated control
forming the torque.
238 Flux Value
Magnetic flux calculated according to the rated
values and the operating point of the motor.
239 Reactive Current
Reactive current calculated from the rated motor
parameters, the control variables and the current
240 Actual Speed Measured and/or calculated speed of drive.
241 Actual Frequency Measured and/or calculated frequency of drive.
Note: The actual values can be read out and monitored in the VAL menu
branch of the operating unit. The parameter
Control Level 28 in the
PARA menu branch defines the selection of the actual value parameters
to be selected.
