7.2.2 Data Set
The data set change-over function enables the selection of one of four data sets for
storing parameter settings.
If data set 0 is selected (factory setting), the parameter values stored in data set 0 are
copied to data sets 1 through 4. In this way, all values determined during the guided
commissioning procedure are saved in all data sets. In the factory settings, the fre-
quency inverter uses data set 1 as the active data set. (For information on data set
change-over via logic signals, refer to the chapter "Data Set Change-Over").
For example, if data set 2 is selected for guided commissioning ("SETUP"), all values
which were determined or entered are saved in this data set. In this case, the other
data sets do not contain any defined values. For the operation of the frequency in-
verter, data set 2 must be selected as the active data set in this case.
Data Set Setup
dS Function
0 All data sets (DS0)
1 Data set 1 (DS1)
2 Data set 2 (DS2)
3 Data set 3 (DS3)
4 Data set 4 (DS4)
7.2.3 Motor Type
The properties of the control functions and methods to be set vary depending on the
motor which is connected. The parameter
Motor type 369 offers a range of motor
variants with the corresponding table values. The verification of the entered rated val-
ues and the guided commissioning are carried out on the basis of the parameterized
motor type. The selection of motor types varies depending on the requirements of the
different control methods. In operating instructions the functionality and operating
performance are described for 3-phase motors.
Motor type 369 Function
0 - Unknown The motor is not a standard type.
1 - Asynchronous Three-phase asynchronous motor, squirrel cage.
2 - Synchronous Three-phase synchronous motor.
3 - Reluctance Three-phase reluctance motor.
10 - Transformer Transformer with three primary windings.
Caution! Polling and presetting of parameter values depends on the operation mode
selected for parameter
Motor type 369.
If the motor type is not entered correctly, the drive may be damaged.
When the motor type is specified, the machine data must be entered. This is described
in the following chapter. The data are polled in accordance with the table below.
