13.5 Reference Percentage Channel
The reference percentage channel combines various signal sources for definition of
the reference values. The percentage scaling facilitates integration into the applica-
tion, taking various process parameters into account.
The
Reference Percentage Source 476 determines the additive assignment of the
available reference value sources depending on the hardware installed.
reference percentage source 476 Function
1 - Abs. Analog Value MFI1A
Reference value source is the multifunctional
input 1 in
Operation Mode 452 - Analog signal.
10 - Abs. Fix. Perc. Val. (FP)
The percentage according to
Fixed Percent
Change-Over 1
75, Fixed Percent Change-Over
2
76 and the current data set.
11 - Abs. Value MFI1A + FP Combination of operation modes 1 and 10.
20 - Abs. Value Motorpoti (MP)
Reference value source is the function
Percent
Motorpoti Up
72 and Percent Motorpoti
Down
73.
21 - Abs. Value MFI1A + MP Combination of operation modes 1 and 20.
32 -
Abs. Repetition Frequency
Input (F3)
The frequency signal on the digital input accord-
ing to
Operation Mode 496 of the repetition fre-
quency input.
33 - Abs. Val. MFI1A + F3 Combination of operation modes 1 and 32.
90 -
Abs. Value MFI1A + FP +
MP + F3 (+ EM-S1INA)
1)
Combination of the operation modes 1, 10, 20, 32
(+ analog input of an extension module)
1)
.
101 to 190 Operation modes with signs (+/-).
1)
The reference value source is only available if an optional extension module with
analog input is connected. For information, refer to the extension module operating
instructions.
13.5.1 Block Diagram
The following table describes the software switches shown in the circuit diagram as a
function of the selected
Reference Percentage Source 476.
Switch position on circuit diagram
Operation
mode
MFI1A FP MP F3 Sign
1 1 Abs. value
10 1 Abs. value
11 1 1 Abs. value
20 1 Abs. value
21 1 1 Abs. value
32 1 Abs. value
33 1 1 Abs. value
90 1 1 1 1 Abs. value
101 1 +/-
110 1 +/-
111 1 1 +/-
120 1 +/-
121 1 1 +/-
132 1 +/-
133 1 1 +/-
190 1 1 1 1 +/-
