Operating Instructions ACTIVE 06/07140

140 Operating Instructions ACTIVE 06/07

Warning code Operation mode 536

A 0001 0000 UDdyn 30 - Controller Udc Dynamic Operation

A 0002 0000 UDstop 31 - Controller Shutdown

A 0004 0000 UDctr 32 - Controller Mains Failure

A 0008 0000 UDlim 33 - Controller Udc Limitation

A 0010 0000 Boost 34 - Controller Voltage Pre-Control

A 0020 0000 Ilim 35 - Controller I abs

A 0040 0000 Tlim 36 - Controller Torque Limitation

A 0080 0000 Tctr 37 - Controller Torque Control

A 0100 0000 Rstp 38 - Ramp Stop

A 0200 0000 IxtLtlim 39 - Contr. Intel. Curr. Lim. LT-Ixt

A 0400 0000 IxtStlim 40 - Contr. Intel. Curr. Lim. ST-Ixt

A 0800 0000 Tclim 41 - Contr. Intel. Curr. Lim. Tc

A 1000 0000 MtempLim 42 - Contr. Intel. Curr. Lim. Motor Temp.

A 2000 0000 Flim 43 - Controller Freq. Limitation

14.4 Digital Inputs

The assignment of the control signals to the available software functions can be

adapted to the application in question. Depending on the

Configuration 30 selected,

the default assignment or the selection of the operation mode differ. In addition to

the available digital control inputs, further internal logic signals are available as

sources.

The individual software functions are assigned to the various signal sources via pa-

rameterizable inputs. This enables a flexible use of the digital control signals.

Digital Inputs Function

6 - On Signal input is switched on.

7 - Off Signal input is switched off.

13 -

Technology Controller

Start

Start command technology controller (configura-

tion 111 or 411).

61 - Error Signal Output Monitoring function signals an operational fault.

70 - S1IND

Signal at digital input S1IND (X210A.3)

(controller release linked permanently).

71 - S2IND

Signal at digital input S2IND (X210A.4) or remote
