Operating Instructions ACTIVE06/07 83
06/07 Operating Instructions ACTIVE 83
The individual steps of the auto set-up routine can be monitored and checked via pa-
rameter
SETUP Status 797. The setup routine via the communication interface continu-
ously updates the status parameter which can be read out via the interface.
Status Messages
Message Meaning
Ok Auto set-up routine has been carried out.
PC Phase 1 The plausibility check of the motor data is active.
PC Phase 2 The calculation of dependent parameters is active.
S1IND
The parameter identification requires a controller release
signal at digital input S1IND.
Parameter identification
The rated motor values are checked by the parameter identi-
fication feature.
Setup already active The setup routine via the control unit is being carried out.
No release signal
The parameter identification requires a controller release
signal at digital input S1IND.
Error Error during the auto set-up routine.
Warning
phase asymmetry
The parameter identification feature diagnosed an unbalance
during the measurements in the three motor phases.
Warning Messages
Code Message Meaning
SA0001
Rated
Voltage
The value of the parameter
Rated voltage 370 is out of the
rated voltage range of the frequency inverter. The maximum
reference voltage is indicated on the rating plate of the fre-
quency inverter.
SA0002 Efficiency
For a three-phase motor, the calculated efficiency is in the
limit range. Check and correct, if necessary, the values en-
tered for the parameters
Rated voltage 370, Rated current
371 and Rated power 376.
SA0003
Rated
Cos Phi
The value entered for parameter
Rated cos phi 374 is out-
side of the normal range (0.6 to 0.95). Correct the value.
SA0004
Slip
Frequency
For three-phase motor, the calculated slip is in the limit
range. Check and, if necessary, correct
Rated speed 372 and
Rated frequency 375.
Error Messages
Code Message Meaning
SF0001
Rated cur-
rent too low
The value entered for parameter
Rated current 371 is too
low. Correct the value.
SF0002
Rated cur-
rent too
high
The value for parameter
Rated current 371 is too high, re-
ferred to parameters
Rated power 376 and Rated voltage
370. Correct the values.
SF0003
Rated Cos
Phi
The value entered for parameter
Rated cos phi 374 is wrong
(greater than 1 or smaller than 0.3). Correct the value.
SF0004
Negative slip
frequency
The calculated slip frequency is negative. Check and, if nec-
essary, correct the values entered for parameters
Rated
speed
372 and Rated frequency 375.
SF0005
Slip
frequency
too large
The calculated slip frequency is too high. Check and, if nec-
essary, correct the values entered for parameters
Rated
speed
372 and Rated frequency 375.
SF0006
Output
balance
The calculated total output of the drive is lower than the
rated power. Correct and check, if necessary, the value en-
tered for parameter
Rated power 376.
SF0007
Config. not
supported
The set configuration is not supported by the auto set-up
routine.
