Operating Instructions ACTIVE06/07 87
06/07 Operating Instructions ACTIVE 87
In the table, you will find a list of functions which are available in the different configurations.
Configuration
V/f - charac-
teristic
field-oriented control
sensorless sensorless sensor
Function Chapter
110 111 410 411 430 210 211 230
Speed control 16.5.3 x x x x x
Torque control 16.5.2 x x
Switch-over speed/torque con-
trol
14.4.6 x x
Dynamic Voltage Pre-Control 15.1 x x
Intelligent current limits 16.1 x x x x x x x x
Voltage controller 16.2 x x x x x x x x
Technology controller: 16.3 x x x
− pressure control 16.3 x x x
− flow rate control 16.3 x x x
− Contents level control 16.3 x x x
− Speed control 16.3 x x x
Slip compensation 16.4.1 x
Current limit value controller 16.4.2 x x
Current Controller 16.5.1 x x x x x x
Limit Value Sources 16.5.2.1 x x x x x x
Acceleration Pre-Control 16.5.4 x x x x x x
Field Controller 16.5.5 x x x x x x
Modulation Controller 16.5.6 x x x x x x
Starting behavior: 11.1 x x x x x x x x
− Starting current impression 11.1.1.1 x x x x x
− Flux Formation 11.1.2 x x x x x x
Stopping behavior: 11.2 x x x x x x x x
− Direct current brake 11.3 x x
Auto Start 11.4 x x x x x x x x
Search Run 11.5 x x x x x x x x
Reference point positioning 11.6.1 x x x
Axle Positioning 11.6.2 x
Frequency Reference Channel 13.4 x x x x x
Reference percentage channel 13.5 x x x x x
Fixed Frequencies 13.6.1 x x x x x x x
Fixed Percentages 13.6.3 x x x x x
Block Frequencies 13.9 x x x x x x x
Repetition frequency input 13.11 x x x x x x x x
Brake Chopper 17.4 x x x x x x x x
Motor Circuit Breaker 17.5 x x x x x x x x
V-belt Monitoring 17.6 x x x x x x x x
Motor Chopper 17.7.1 x x x x x x
Temperature Adjustment 17.7.2 x x x x x x
Encoder Monitoring 17.7.3 x x x
