Spont Rate
Range/Performance: 0 to 99 bpm.
Tolerance: ±1 bpm
% Spont
Range/Performance: 0 to 100%.
SpO
2
Range/Performance: 70 to 100%.
Tolerance: ±3 digits. No motion and flex sensor.
Pulse Rate
Range/Performance: 25 to 240 bpm.
Tolerance: ±3 digits. No motion and flex sensor.
I:E
Range/Performance: 1:10 to 10:1.
Tolerance: ±0.1 unit for I:E < 9.9, ±1 unit otherwise.
Insp. Time
Range/Performance: 0.3 to 5 s.
Tolerance: ±0.1 s
Rise Time
Range/Performance: 0.1 to 5 s.
Tolerance: ±10% or ±0.1 s, whichever is greatest
8.2.5 Power Supply
AC supply: 100 to 240 V AC, tolerance: +10%/-20%, 50 to 60 Hz, 1.0 - 2.0 A.
External DC: 19 V DC, tolerance: 19 V ± 6 V. Max 90 W.
Click-in battery: Capacity: 65Wh. Li-ion.
Internal battery: Capacity: 25Wh. Li-ion. Expected service life: 500 full charging cycles.
8.2.6 Environmental Conditions
Operating temperature range: 5 to 40°C (41 to 104°F)
Storage and transport temperature: -20 to +60°C (-4 to +140°F)
Ambient pressure range:
700 to 1100 mbar, corresponding to
~4200 metres (13800 feet) above sea level
to ~700 metres(2300 feet) below sea level,
at normal atmospheric pressure.
As seen in the graph above, the ventilator
is unable to deliver set max pressure at a
very low ambient pressure.
