3.3 Side Views
Click-in compartment side
1 2 3 4 5 6
7
8
9
No Item Function
1
Audio pause Pause the alarm sound
2
Start/Stop Start/Stop ventilation
treatment
3 Patient air outlet Connection for patient circuit
4
Air bypass unit
Click-in airway/silencer for
use without the click-in
humidifier. (If the click-in
humidifier is used, it replaces
the air bypass unit)
5
Click-in compartment Compartment for either of
the accessories click-in
humidifier or click-in battery.
6 Side panel Cover
7
Carrying handle Handle for lifting the
ventilator
8 Cooling air outlet Outlet internal cooling
9 Cooling air inlet Inlet internal cooling
