Parameter Example
Ventilator Settings
Mode
PCV
IPAP
20 cmH
2
O
EPAP 4 cmH
2
O
Breath Rate* 20 bpm
Insp. Time* 1.0 s
I:E 1:2
Insp. Trigger Off
Rise Time 1
Target Volume Off
Display Light* Off
Light Intensity*
-
Monitored Value
Tidal Volume 800 ml
Resistance
5 hPa (l/s)
-1
Compliance 50 ml (hPa)
-1
*: These ventilator settings affect the operating time significantly
Battery
Operating Time
Internal Battery 2.5 h
Click-in Battery 6.5 h
5.11.7 Storing the Internal Battery and the Click-in Battery
Storage longer than 1 month should be initiated with half-charged batteries in order to main-
tain maximum capacity. Optimal storage temperature is 5 to 30°C (41 to 86°F).
5.11.8 External DC
WARNING!
Do not connect the ventilator to a wheelchair unless the operating manual for the wheel-
chair permits this as this can affect the ventilator performance and consequently result in
patient death.
How to Use the Nippy 4
65
Doc. 006553 M-6 User Manual
