Supplemental oxygen flow and pressure must not exceed 30 l/min and 100 kPa.
CAUTION!
Supplemental oxygen is added before the volume measurement sensor and thereby
included in the measurements. However, the oxygen concentration still has influence on
the volume measurement of the delivered air.
This measurement is based on a normal oxygen concentration of 21%. If the oxygen
concentration is higher, the actual inspired volume will deviate from the monitored vol-
ume as follows:
• 40% oxygen concentration: -2.5% deviation
• 60% oxygen concentration: -5% deviation
• 80% oxygen concentration: -7.5% deviation
24
Safety Information
User Manual
Doc. 006553 M-6
