Target Volume Parameters
When target volume is on, the following parameters are enabled:
Max Pressure
Max Pressure defines the upper pressure limit up to where the ventilator can increase the
pressure to reach the set Target Volume. If Target Volume is not reached at Max Pressure,
the ventilator will continue to ventilate at this Max Pressure setting.
Unit Min Max Default
cmH
2
O
Current Min Pressure 40 15
Min Pressure
Min Pressure defines the lower pressure limit down to where the ventilator can decrease
the pressure to maintain the set Target Volume. If the actual volume is above Target Vol-
ume at Min Pressure, the ventilator will continue to ventilate at this Min Pressure setting.
Unit Min Max Default
cmH
2
O 4 Current Max Pressure 15
5.6.2.14 CPAP
The CPAP setting defines the pressure that will be applied to the airways in CPAP mode.
Unit Min Max Default
cmH
2
O 4 20 10
5.6.2.15 Ramp Time
The Ramp Time setting defines the time during which the pressure will increase from the
set Start Pressure to the set Inspiratory Pressure.
Ramp Time can only be set in Clinical Mode.
Unit Min Max Default
Minute 10
Off
60 Off
5.6.2.16 Start Pressure
The Ramp Start Pressure defines the pressure level delivered by the ventilator at the begin-
ning of the Ramp Time.
Unit Min Max Default
cmH
2
O 2 Current IPAP–2 5
5.6.2.17 Always Start Ramp
The Always Start Ramp determines whether the ramp is started automatically at the begin-
ning of the treatment.
How to Use the Nippy 4
53
Doc. 006553 M-6 User Manual
