3-14
Confidential
2 Main PCB
3 Main PCB/Modem PCB
Second side CIS
flat cable
First side CIS
flat cable
Main PCB
Harness holder
Cable guide
Carriage flat cable
Ink sensor flat cable
Modem PCB flat cable
Cable guide
Ink cartridge cover sensor harness
Speaker harness
Maintenance cam harness
Cap cam harness
ASF encoder sensor
Flat cores
harness
Cable
guide
