Brother MFC-J2330DW Service Manual

3-61
Confidential
Assembling Note: Assemble a new First side CIS flat cable by bending the First side
CIS flat cable and affixing the Double-sided adhesive tape as
shown in the figure below.
Fig. 3-52
Routing of harnesses: See “ ADF unit/Document scanner unit”.
Double-sided
adhesive tape
Double-sided
adhesive
17mm
(237.5)
mm
1074
10
45°
45°
±15
mm
±3.5°
±3.5°
±2
mm
Supporting tape
Terminal
To main body
Mountain fold
Valley fold
Supporting
tape
45°
±3.5°
165.1±2mm
12.8±1mm
236.1±2mm
237.5±2mm
315.6±2mm
25.2±2mm
13.6±1mm
84.6°
±3.5°
10±2mm
0 to 2mm
(315.6)
mm
(17) mm
Supporting
tape
Double-sided
adhesive tape
0 to 2mm
0 to 2mm
(14) mm
(1.5) mm
0 to 2mm
(17) mm
tape
(1.5) mm
(14) mm
(237.5)
mm
(315.6)
mm
To CIS unit
To CIS unit
(10) mm
7

Brother MFC-J2330DW Specifications

General

Print Technology	Inkjet
Functions	Print, Copy, Scan, Fax
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Scan Resolution	1200 x 2400 dpi
Fax Speed	33.6 kbps
Max Print Resolution	4800 x 1200 dpi
Print Speed (Black)	22 ppm
Print Speed (Color)	20 ppm
Duplex Printing	Automatic
Display	2.7" Touchscreen
ADF Capacity	50 sheets
Supported Paper Sizes	A3, A4
Operating System Support	Windows, macOS, Linux
Scanner Type	Flatbed, ADF
Mobile Printing	Brother iPrint&Scan, AirPrint, Google Cloud Print
Ink Cartridges	Black, Cyan, Magenta, Yellow
Paper Input Capacity	250 sheets
