Brother MFC-J2330DW Service Manual

5-68
Confidential
AMS03 (Printing assurance 3)
- Selectors 5 and 6: Measure for black streaks at trailing edge of recording
paper
When the trailing edge of the recording paper goes through the paper feed roller,
black streaks may appear on the printed paper in the case of high-density
printing, because the paper is stretched around the paper ejection roller.
While the feed amount is corrected based on printing density, the level of stretch
differs by material of the recording paper. Therefore, black streaks at the trailing
edge of the paper should be improved by switching the feed correction value for
the paper.
AMS04 (Maintenance assurance 2)
- Selectors 2: LED display setting in Sleep Mode
You can select either OFF or blinking as the state of the power LED in the Sleep
Mode.
Selector
No.
Function Setting and Specifications
1
|
4
Not used.
5
6
Measure for black streaks at
trailing edge of recording paper
No. 5 6
0 0 : Machine correction value (default)
0 1 : 1/2 of machine correction value
0 0 : 2/3 of machine correction value
1 0 : No correction
7
8
Not used.
Selector
No.
Function Setting and Specifications
1 Not used.
2
LED display setting in Sleep
Mode
0: Blinking (default) 1: OFF
3
Not used.
4
Automatic purging for color ink 0: Enable (default)1: Disable
5 Not used.
6 Periodic purge
0: Enable (default)1: Disable
7 Not used.
8 Automatic purging for black ink
0: Enable (default)1: Disable

Brother MFC-J2330DW Specifications

General

Print Technology	Inkjet
Functions	Print, Copy, Scan, Fax
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Scan Resolution	1200 x 2400 dpi
Fax Speed	33.6 kbps
Max Print Resolution	4800 x 1200 dpi
Print Speed (Black)	22 ppm
Print Speed (Color)	20 ppm
Duplex Printing	Automatic
Display	2.7" Touchscreen
ADF Capacity	50 sheets
Supported Paper Sizes	A3, A4
Operating System Support	Windows, macOS, Linux
Scanner Type	Flatbed, ADF
Mobile Printing	Brother iPrint&Scan, AirPrint, Google Cloud Print
Ink Cartridges	Black, Cyan, Magenta, Yellow
Paper Input Capacity	250 sheets
