Brother MFC-J2330DW Service Manual

Confidential
2-18
Error Message State
Error
Code
Reference
Jam Front/Rear
Jam Front
Jam Rear
Jam MP Tray
Jam Front/MP Tray
Jam Tray2
Paper Jam
Repeat Jam
Repetitive Paper Jams
Paper jam during duplex-printing
The recording papers are fed in reverse on the
platen when switchback drive is started, triggering
switchback sensor as paper feeding condition.
0D00
2-24
Defective during duplex-printing
Switchback sensor detects paper feed condition at
out of specified timing during switchback.
0E00 2-24
Defective during duplex-printing
Registration sensor detects paper feed condition
at out of specified timing during switchback.
1300 2-25
Paper jam during duplex ejecting
Recording paper is not able to be ejected since it
is longer than 840 mm when ejecting the paper.
1500 2-25
Paper jam during duplex-printing
Registration sensor does not detect paper feed
within specified pulse numbers in the second side
paper re-feed.
1800 2-26
Carriage cannot detect origin.
Detected by the CR encoder sensor.
3100 2-32
Abnormal stop of head/carriage unit being driven
Caused by paper jam when ink is not discharging
3800 2-33
Abnormal stop of head/carriage unit being driven
Caused by paper jam when ink is discharging
3C00 2-34
Paper jam
Paper width sensor cannot detect leading edge or
width of recording papers.
8200 2-45
Paper jam
Registration sensor stays in paper feeding state
even after completion of paper ejection action.
8400 2-45
Paper jam
Switchback sensor stays in paper feeding state
even after completion of paper ejection action.
8700 2-46
Paper jam
Switchback sensor cannot detect paper feeding
state even papers are fed during printing.
8800 2-46
Low Temperature It was detected that the head temperature is the
specified value or less.
4300 2-36
It was detected that the machine temperature is
the specified value or less.
4000 2-35
Media is Full The memory in the media slot is full, or there are
999 or more files.
No Caller ID There is no caller ID information.
No Paper Fed
Repetitive No Paper Fed
It is detected that there is no recording paper in
the valid trays for printing.
--- 4.2.9
Out of Fax Memory
Out of Memory
The memory becomes full. --- 4.10.4

Brother MFC-J2330DW Specifications

General

Print Technology	Inkjet
Functions	Print, Copy, Scan, Fax
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Scan Resolution	1200 x 2400 dpi
Fax Speed	33.6 kbps
Max Print Resolution	4800 x 1200 dpi
Print Speed (Black)	22 ppm
Print Speed (Color)	20 ppm
Duplex Printing	Automatic
Display	2.7" Touchscreen
ADF Capacity	50 sheets
Supported Paper Sizes	A3, A4
Operating System Support	Windows, macOS, Linux
Scanner Type	Flatbed, ADF
Mobile Printing	Brother iPrint&Scan, AirPrint, Google Cloud Print
Ink Cartridges	Black, Cyan, Magenta, Yellow
Paper Input Capacity	250 sheets
