Brother S-710A - 5-9. Quick Reverse Solenoid Disassembly

5. DISASSEMBLY
SL-710A
21
5-9. Quick reverse solenoid
2
Quick reverse solenoid
1
Screw [3 pcs]
1677M
1676M
2
Screw [Loosen]
10
Felt
9
Bed under cover
3
Oil tubes
11
Oil gauge guide
8
Screws
[8 pcs]
1
Screw
Lubricating
oil
Lubricatin
g
oil
4
Screws [2 pcs]
5
Oil tank
-3[][] • -4[][]
1675M
While holding a pan under the gear box,
loosen the eight screws.
* The oil inside the gear box will start flowing
out from the gear box when you start to
loosen the eight screws.
1) Place a dish under the lubricating oil
outlet, and then remove the screw and
drain the lubricating oil.
2) Securely tighten the screw into the
lubricating oil outlet.
<DD7100>
7
Knee lifter arm connecting rod
6
Shoulder screw
