Brother S-710A - 5-10. Needle, Presser Foot, and Reverse Actuator Assy Disassembly; 5-11. Thread Tension Mechanism Disassembly; 5-12. Needle Plate and Feed Dog Disassembly

5. DISASSEMBLY
SL-710A
22
5-10. Needle, presser hoot and reverse actuator assy
5-11. Thread tension mechanism
5-12. Needle plate and Feed dog
7
Reverse actuator assy
6
Screws [2 pcs]
2 N
eedle
1
Set screw
3
Screw
4
Finger guard
5
Presser hoot
<Presser foot with integrated
finger guard>
1679M
1678M
1
Set screw [Loosen]
4
Arm thread guide
2
Pre-tension assy
3
Screw
6
Thread tension bracket assy
7
Pin
8
Tension release stud
5
Set screw [Loosen]
10
Thread guide D
9
Thread guide
1680M
1
Screws [2 pcs]
2
Needle plate
6
Screw
7
Ruler plate
5
Feed dog
4
Screws [2 pcs]
3
Slide plate
1681M
