Brother S-710A - 5-22. Lower Shaft, Lower Shaft Gear, and Feed Regulator Set Disassembly; 5-23. Plunger, Rotary Hook Shaft, Gear, and Thread Trimmer Cam Disassembly

5. DISASSEMBLY
SL-710A
27
5-22. Lower shaft, lower shaft gear and feed regulator set
5-23. Plunger, rotary hook shaft, gear and thread trimmer cam
6
Lower shaft [Pull out]
1
Set screw
[
2 pcs: Loosen
]
8
Lower shaft gear
2
Set screw
[
2 pcs: Loosen
]
3
Set screw
[
2 pcs: Loosen]
7
Feed regulator set
5
Spacer [2 pcs]
4
Set screw [2 pcs]
4
Set screw
[
4 pcs: Loosen
]
<DD7100>
1698M
1699M
1700M
8
Rotary hook shaft [Pull out]
10
Thread trimmer cam
9
Gear
7
Set screw [2 pcs: Loosen]
5
Spacers [2 pcs]
6
Set screw [2 pcs: Loosen]
4
Set screws [2 pcs]
3
Plunger
2
Spring
1
Ca
p
screw
