Brother S-710A - 6-32. Bed Cover and Knee Lifter Lever Installation

6. ASSEMBLY
SL-710A
60
6-32. Bed cover and knee lifter lever
1. Install the bed cover (1) to the bed.
2. For sub-classes -30[], -31[], -40[] and -41[], push the
knee lifter lever (2) onto the knee lifter shaft (3).
1809M
(3)
(1)
(2)
(DD7100A,710A)
(DD7100)
