12-5. Memory switches
Memory switches 01 - 08
ON Parameter setting can be changed.
01 Parameter setting
OFF Parameter setting change is prohibited.
ON
Forward step is possible during backward step
(for thread trimming).
02 Interlocking along with forward step
OFF
Forward step is impossible during backward step
(for thread trimming).
ON
Power supply drop check (reset detection) function is
activated.
03 Power supply drop check
OFF Without the above-mentioned function
ON
The same as settings of DIP switches 6 and 7.
(See NOTE 1.)
04 Limited sewing speed
OFF Maximum sewing speed is limited to 4,700rpm.
ON Needle penetration force is strong.
05 Needle penetration force
OFF Needle penetration force is ordinary.
ON Overtime function disabled
06 Overtime function
OFF Overtime function enabled (3 minutes)
ON Backtacking speed is not limited by high speed setting
07
Independent backtacking speed
setting
OFF Backtacking speed is limited by high speed setting
ON
Number of stitches and sewing speed can be set using the
operation panel
08
Slow start function (From design
change C onward)
OFF Low speed is fixed at 2 stitches
(NOTE 1) When the power is turned on again, sewing speed can be set up to 5,000 rpm.
Memory switches 11 - 18
ON Without thread trimming and thread wiper
11
Thread trimming and thread wiper
output
OFF With thread trimming and thread wiper
ON Presser foot is raised when the foot pedal is in neutral.
12
Presser foot position after thread
trimming (See NOTE 2.)
OFF Presser foot is lowered when the foot pedal is in neutral.
ON Presser foot is at its highest position.
13
Presser foot position after the machine
stops with the pedal in neutral
OFF Presser foot is at its lowest position.
ON It is used as the thread trimming switch.
14 Actuator switch
OFF It is used as the reverse and correction switches.
ON Ordinary slowdown stop and control
15 Slowdown stop control
OFF Slowdown and stop control with 1 stitch elimination
ON Unable to be used
16 Lower thread remaining detection
OFF Able to be used.
ON A forward stitch or half stitch can be corrected. (See NOTE 3.)
17 Half-stitch correction
OFF
A forward stitch can be corrected. A half stitch cannot be
corrected. (See NOTE 3.)
ON
A forward stitch or reverse stitch can be corrected.
(See NOTE 3.)
18 Reverse stitch correction
OFF
A forward stitch can be corrected. A reverse stitch cannot be
corrected. (See NOTE 3.)
(NOTE 2) It is activated when DIP switch 1 is set to on.
(NOTE 3) A forward stitch can be corrected when the LED of the correction switch is lit. A half stitch or reverse stitch can
be corrected when the LED of the correction switch is not lit.
