12. FUNCTION SETTING METHODS
SL-710A
88
Memory switches 21 - 28
ON
Start backtacking is performed in the order of lengths A, B, A,
then B.
21 Double start backtacking
OFF Start backtacking is performed in the order of lengths A and B.
ON
End backtacking is performed in the order of lengths C, D, C,
and D (B, A, B, and A on the B-20 operation panel).
22 Double end backtacking
OFF
End backtacking is performed in the order of lengths C and
D (B and A on the B-20 operation panel).
ON
Extra 10 stitches are added to the number of stitches set for
both lengths A and B.
23
Number of stitches for start
backtacking plus 10 stitches
OFF No extra stitches are added.
ON
Extra 10 stitches are added to the number of stitches set for
both lengths C and D
(B and A on the B-20 operation panel).
24
Number of stitches for end
backtacking plus 10 stitches
OFF No extra stitches are added.
ON The machine will stop with the reverse feed remaining on.
25
Feed direction when the start
backtacking is completed
OFF The machine will stop after feed is returned to normal.
ON End backtacking will start without speed slowing down.
26 Start end backtacking
OFF
The machine will slow the sewing speed gradually to start
low speed sewing, then shift to end backtacking.
ON
Forward stitching for the number of stitches set in the A
display, and backward stitching for the number of stitches set
in the B display will be performed repeatedly for the number
of times set in the D display. (The C display will be blank.)
27 Continuous backtacking setting
OFF
Continuous stitching will be performed for lengths A, B, C,
and D as specified in the ABCD displays.
ON Extra 10 stitches are added to each lengths A, B, C, and D.
28
Number of stitches for continuous
backtacking plus 10 stitches
OFF No extra stitches are added.
Memory switches 31 - 38
ON
Sewing can be suspended by returning the foot pedal to
neutral. During start backtacking, sewing speed depends on
the foot pedal stroke.
31
Start backtacking suspension by foot
pedal being placed in neutral or
backtacking speed change during the
start backtacking
OFF
Sewing can not be suspended by returning the foot pedal to
neutral. During start backtacking, sewing speed is fixed
regardless of the foot pedal stroke.
ON
The number of backtack stitches for fixed stitching, label
attaching, or pleats presser sewing can be changed.
32
The number of backtack stitches on
the B-20 or B-40 operation panel
OFF
The number of backtack stitches is fixed to 4 (for fixed
stitching, label attaching, and pleats presser sewing) (See
NOTE 4)
ON Without reverse stitching (Fixed stitching will be called back.)
33 Pleats presser stitching direction
OFF With reverse stitching (Ordinary pleats presser stitching)
ON -
34 -
OFF -
ON Manual soft drop function (NOTE 5)
35 Presser foot soft drop function
OFF Automatic soft drop function (NOTE 6)
ON
Timer-off function is not activated. (Presser foot will not be
lowered by timer.)
36 Presser foot timer-off function
OFF Timer-off function is activated. (See NOTE 7)
ON Pneumatic-type presser lifter-compatible (Duty 1:1)
37
Automatic presser lifter output selection
(From design change B onward)
OFF Solenoid-type presser lifter-compatible (Duty 1:6)
ON
38
OFF
(NOTE 4) For the B-40 operation panel, the number of end backtack stitches can be changed for fixed stitching or
pleats presser sewing.
(NOTE 5) Adjustment is required using parameter No. 15. If set to "00", response is fastest and operating noise increases.
(NOTE 6) Can be adjusted using parameter No. 16. If set to "10", response is fastest and operating noise increases.
(NOTE 7) Timer-off function is not activated when parameter No.14 is set to 00.
