Brother S-7300A - Page 20

S-7300A
3. FUNCTION SETTINGS
9
Sewing machine motor settings (100 to 199)
No. Setting range Initial value
Setting
units
Setting details
100
OFF, 1
～
3
OFF
1 Slow control after sewing start
OFF: Disabled
1: Only at the sewing start after thread trimming
2: Only when sewing is restarted
3: Usual operation
101
1
～
5
1
1
Degree of slow startup immediately after sewing start
(A larger number means a slower startup)
(*) This is not displayed when MSW-100 is set to "OFF".
102
-10
～
10
(Degrees)
0
(Degrees)
1 Needle up stop position correction value
・
This is not initialized during initialization mode.
103
-10
～
10
(Degrees)
0
(Degrees)
1
Needle down stop position correction value
・
This is not initialized during initialization mode.
150
ON/OFF
ON
－
Stop control when treadle is returned to neutral position
ON: Control is carried out to stop quickly in a fixed length of time
* Low speed operating time before sewing stops is almost constant
OFF: Above control is not used
* Low speed operating time before sewing stops is not constant
151
OFF, 1
～
2
1
1
Needle penetration up operation
(Effective hammer operation if needle does not pierce)
OFF: Not used
1: Only needle goes down
(Does not operate during thread trimming
operation)
2: For all movement
(Operation is enabled during thread trimming
operation also)
152
ON/OFF
OFF
－
Highest needle position stop operation after thread trimming
ON: Used
OFF: Not used
153
50
～
500
(ms)
150
(ms)
10
(ms)
Delay time after thread trimming from needle up stop until reverse
operation starts.
(*) Only displayed when MSW-152 is set to "ON"
154
-120
～
-40
(Degrees)
-60
(Degrees)
1
Reverse needle up stop position from needle up stop position setting
(*) Only displayed when MSW-152 is set to "ON"
155
0
～
1
0
1
Wiper OPE when reversing highest NEDL and TIMG of presser foot OPE
(*) Only displayed when MSW-152 is set to "ON"
(*) If the setting for MSW-154 is "-120" or "-81", operation will be according
to the "1" setting (the "0" setting is disabled).
0: The needle is raised, then thread wiping is carried out, and then the
presser foot is raised.
1: Thread wiping is carried out before the needle is raised, and the presser
foot is raised after thread wiping is carried out.
170
5
～
12
(A)
9
(A)
1
Current limit value during acceleration
(*
) When a larger value is set, the acceleration of the sewing machine
motor becomes faster.
When a smaller value is set, the acceleration of the sewing machine
motor becomes slower.
(*) Setting a sm
aller value may be effective in preventing fluorescent light
flickering.
171
5
～
12
(A)
7
(A)
1
Current limit value during deceleration
(*
) When a larger value is set, the deceleration of the sewing machine
motor becomes faster.
When a smaller value is set,
the deceleration of the sewing machine
motor becomes slower.
172
-3
～
6
0
1
Gain during high-speed motor operation
173
-3
～
6
3
1
Gain during low-speed motor operation
174
-3
～
9
6
1
Gain during thread trimming
