Chapter 9 High Accuracy Mode A TC-32B
2004/1/22 9 - 2 eT32BNCPR.9.doc
9
9.1 Outline
High accuracy mode A is a function for highly accurate machining at high speed. It is ideal for
contouring and 3D workpiece machining. This function enables you to machine workpieces at
high speed yet maintain accuracy. It is also possible to change the shape accuracy where
necessary by setting override settings for user parameters. Up to three override patterns can be
set for parameters, and these can be changed in the NC program.
Functions available in high accuracy mode A are given below. See section 4 for details.
(1) Automatic corner deceleration function
(2) Automatic arc deceleration function
(3) Automatic curve approximation deceleration function
Program path
Tool path
Tool path
Program path
Tool path
Program path
Tool path
Program path
Tool path
When high accuracy mode A is OFF When high accuracy mode A is ON
(1) Automatic corne
r
deceleration function
(2) Automatic arc deceleration function
(3 )Automatic curve approximation deceleration function
Tool path
Program path
Program path
