BST ekr CON 600 net Translation Of The Original Manual

4
Communication Objects
28/79 ekr CON 600 net – Process Data Exchange via Profibus
Name Data Type Bit Meaning Data Description
Little
Endian
Big
Endian
12
…
15
20
…
23
Reserved Do not use. Always 0.
16
…
23
8
…
15
Reserved Do not use. Always 0.
24
…
31
0
…
7
Reserved Do not use. Always 0.
Control bit
field 2
Unsigned32
0 24
Blocking (controller
interlock active)
1 25
– Left arrow key
2 26
– Right error key
3 27
Limit switch left side
active
4 28
Limit switch right
side active
5 29 Keyboard interlock
6 30
Motor control
timeout
7 31 Setup lock
8
…
15
16
…
23
Reserved Do not use. Always 0.
16 8
Oscillation switched
on
17 9
Oscillation switched
off
18
…
23
10
…
15
Reserved Do not use. Always 0.
24
…
31
0
…
7
Reserved Do not use. Always 0.
