3.3 Procedure Screen
The Visual-ICE System Procedure Screen provides a single-screen view to control and monitor
a cryoablation procedure. The Procedure Screen is divided into sections for the Navigation Tool
Bar, Context Sensitive Help, Channel Controls, Channel Status, Temperature Sensors, and Organ
Map. The title bar of each section on the Procedure Screen provides user selected self-help for that
section.
1
5
2
3
4
6
Screen 3-3. Procedure Screen
1 Navigation Tool Bar
2 Context Sensitive Help
3 Channel Control
4 Channel Status
5 Temperature Sensors
6 Organ Map
