Button Description
Report Displays a report of all procedure data that has been entered
and captured for the current procedure. The report can be
saved to the Galil Medical USB ash drive. Pressing the
Report button during a procedure displays all procedure
information saved up to that point in time.
End Procedure Ends the current procedure and returns to the Startup Screen.
Pressing this button generates a conrmation request, a
request to save the report, and an option to automatically vent
the system.
3.3.2 Context Sensitive Help
The Context Sensitive Help displays a summary of procedural steps to guide you through a
cryoablation procedure. It is intended to provide only a general overview; step-by-step instructions
are provided in Section 4.1.
3.3.3 User-Selected Self Help
The title bar of each section provides access to additional help information. Press the title bar to
access an explanation of the buttons and elds available in each section of the Procedure Screen.
3.3.4 Channel Controls
Channels 1 through 10 are labeled individually and contain independent controls for Test, Freeze,
Freeze Intensity, Thaw, and Stop. Each individual channel displays the needle type of the needles
connected adjacent to the channel controls (Screen 3-5). The Channel labeled ALL operates all
active channels simultaneously.
Table 3-3. Channel Controls
Button Description
Channel button – Identies the active channel(s).
Advanced Channel Controls: Pressing and holding the
Channel button provides options to change the needle
type selected for that channel, link two adjacent channels
together for simultaneous operation, and program freeze –
thaw cycles.
Channel labeled ALL – Allows testing, freezing, and thawing
on ALL active channels simultaneously. Press the button for
the desired function (Test, Freeze, or Thaw) on this channel to
activate that function on all needles simultaneously.
Test button – Begins the Needle Integrity and Functionality
Testing that is required prior to using any cryoablation needle.
No other controls are enabled until needle testing is complete.
