List of Screens
Screen 3-1. Login Screen 3-1
Screen 3-2. Startup Screen 3-2
Screen 3-3. Procedure Screen 3-3
Screen 3-4. Navigation Tool Bar 3-4
Screen 3-5. Channel Controls and Channel Status section 3-7
Screen 3-6. Active Thaw Channel Status section 3-7
Screen 3-7. Needle Tip Temperature Display 3-7
Screen 3-8. Enlarged Timer 3-8
Screen 3-9. Repositioned Enlarged Timers 3-8
Screen 3-10. Temperature Sensors section 3-9
Screen 3-11. Organ Map section 3-10
Screen 3-12. Procedure Report Example 3-12
Screen3-13.ViewReportsScreen 3-13
Screen 3-14. Export Report Screen 3-13
Screen3-15.CongureSettings 3-14
Screen 3-16. Remote Upload / Download Screen 3-16
Screen 3-17. Successful Upload / Download 3-16
Screen 4-1. Disabled Channel 4-3
Screen4-2.VentGasMessage 4-3
Screen 4-3. Login Screen 4-4
Screen 4-4. Incorrect Login 4-4
Screen 4-5. Reset Password Challenge 4-5
Screen 4-6. Password Reset 4-5
Screen 4-7. Emergency Login 4-5
Screen 4-8. No Gas Connected message 4-9
Screen 4-9. Optimizing Lines message 4-10
Screen 4-10. Procedure Screen 4-10
Screen 4-11. Thawing Mode message 4-11
Screen 4-12. Needle Past Expiration Date message 4-12
Screen 4-13. Select Needle Type Menu 4-12
Screen 4-14. Gas Time Remaining 4-15
Screen 4-15. Export Report screen 4-17
Screen 4-16. Report Exported message 4-17
Screen 4-17. Advanced Thaw Controls FastThaw 4-20
Screen 4-18. Advanced Thaw Controls i-Thaw 4-21
Screen 4-19. Advanced Thaw - Needle Warming 4-21
Screen 4-20. Advanced Thaw - Temperature Display During Thawing 4-22
Screen4-21.CauteryConrmationmessage 4-23
Screen 4-22. 1.5 CX Needle Warming 4-23
Screen 4-23. 1.5 CX Needle Cautery In Progress 4-23
Screen 4-24. Advanced Channel Controls 4-25
Screen 4-25. Linked Channels 4-25
Screen 4-26. Advanced Cycle Controls 4-26
Screen 4-27. Cycle Sequence Controls 4-27
Screen 4-28. Saved Sequence Controls 4-28
