Heating circuit data
11
Logamatic 4323 - Subject to technical modifications.
42
11.1 Heating system selection
Example:
You want to set "Underfloor" for submenu "Heating system" in the main menu
"Heating circ. 2".
Call up the service level. "Gen. parameters" is shown as the first main menu.
Turn the rotary selector until the main menu "Heating circ. + no." appears
(here:
"Heating circ. 2").
The display shows the selected main menu.
Press "Display" to call up a submenu (here: "Heating system").
The display shows the selected submenu.
Hold down "Display" and turn the rotary selector until the required value appears
(here: "Underfloor").
The display shows the set value.
Release "Display" to save your input.
Press "Back" to return to the next level up.
+
+
SERVICE LEVEL
Heating circ. 2
HEAT CIRC. DATA 2
Radiators
Heating system
+
HEAT CIRC. DATA 2
Underfloor
Heating system
Input range Factory setting
Heating system
none
Radiators
Convector
Underfloor
Constant
Low end
Room controller
Radiators
