Buderus Logamatic 4323 Service Instructions

Heating circuit data
11
Logamatic 4323 - Subject to technical modifications.
43
11.2 Renaming the heating circuit
Instead of the description "Heating circ. + no.", you may select a different
designation from the default list.
Call up the service level. "Gen. parameters" is shown as the first main menu.
Turn the rotary selector until the main menu "Heating circ. + no." appears
(here:
"Heating circ. 2").
Press "Display" to call up a submenu (here: "Heating system").
The display shows the selected submenu.
Turn the rotary selector until submenu "Heat circ desig." appears.
The display shows the selected submenu.
Hold down "Display" and turn the rotary selector until the required value appears
(here: "Underfloor").
The display shows the set value.
Release "Display" to save your input.
Press "Back" to return to the next level up.
+
+
HEAT CIRC. DATA 2
Radiators
Heating system
HEAT CIRC. DATA 2
Heating circ.
Heat circ desig.
+
HEAT CIRC. DATA 2
Underfloor
Heating system
Input range Factory setting
Heat circ desig.
Heating circ.
Apartment
Underfloor
Bathroom
Swimming pool
Floor
Cellar
Building
Heating circ.
