Heating circuit data
11
Logamatic 4323 - Subject to technical modifications.
64
11.20Entering the heating circuit actuator
Via the "Servomotor" function, you can enter whether or not the system
is
equipped with a heating circuit actuator (mixer).
The control unit drives the actuator if it is installed in the heating circuit (mixer).
The heating circuit is regulated via the boiler flow temperature if no heating
circuit actuator is installed.
Call up the service level. "Gen. parameters" is shown as the first main menu.
Turn the rotary selector until the main menu "Heating circ. + no." appears
(here:
"Heating circ. 2").
Press "Display" to call up a submenu (here: "Heating system").
The display shows the selected submenu.
Turn the rotary selector until submenu "Servomotor" appears.
The display shows the selected submenu.
Hold down "Display" and turn the rotary selector until the required value appears
(here: "no").
The display shows the set value.
Release "Display" to save your input.
Press "Back" to return to the next level up.
+
+
HEAT CIRC. DATA 2
Radiators
Heating system
HEAT CIRC. DATA 2
yes
Servomotor
+
HEAT CIRC. DATA 2
no
Servomotor
Input range Factory setting
Servomotor
yes
no
yes
