2006 Buell Lightning: Chassis 2-3
HOME
Front isolator bracket mounting fas-
tener
49-51 ft-lbs 66-69 Nm page 2-63
Front isolator snubber, upper 12-36
in-lbs
1-4 Nm page 2-63
Front isolator threaded frame insert 59-61 ft-lbs 80-82.7 Nm LOCTITE 222,page 2-63
Hand lever pivot fastener 39-48
in-lbs
4.4-5.4 Nm page 2-30
Handlebar clamp screws 10-12 ft-lbs 14-16 Nm tighten front screws first, page 2-79
Heel guard fasteners, passenger 48-72
in-lbs
5.4-8 Nm page 2-86
Heel guard fasteners, rider 72-96
in-lbs
8-11 Nm page 2-85
Horn 72-96
in-lbs
8-10.8 Nm page 2-76
Lower fork clamp fasteners 20-22 ft-lbs 27.1-29.8 Nm LOCTITE 272 (red), page 2-55
Master cylinder banjo bolt, front 16-20 ft-lbs 22-27 Nm page 2-33
Master cylinder banjo bolt, rear 16-20 ft-lbs 22-27 Nm page 2-42
Master cylinder cover fasteners, front 9-13
in-lbs
1.0-1.5 Nm page 2-31
Master cylinder mounting fasteners,
rear
72-96
in-lbs
8-11 Nm page 2-40
Mirror adjuster 115-130
in-lbs
3-14.7 Nm page 2-81
Mirror mount onto bracket 20-22 ft-lbs 27.1-29.8 Nm page 2-81
Muffler mounting block fastener, rear 32-36 ft-lbs 43-49 Nm page 2-84
Muffler strap fastener, front 108-120
in-lbs
12-14 Nm page 2-84
Muffler strap fastener, rear 48-60
in-lbs
5-7 Nm page 2-84
Negative battery cable at battery ter-
minal
72-96
in-lbs
8-11 Nm page 2-72
Oil cooler air scoop 48-72
in-lbs
5.4-8 Nm page 2-92
Oil drain plug 29-34 ft-lbs 39-46 Nm page 2-61
Oil line fittings 108-156
in-lbs
12-17.6 Nm page 2-61
Oil line p clamps at swingarm 48-72/
in-lbs
5.4-8/Nm page 2-62
Pivot shaft pinch bolt 17-19 ft-lbs 23-26 Nm page 2-62
Ram air scoop 12-36
in-lbs
1.4-4 Nm page 2-92
Rear brake line p-clamp 36-60
in-lbs
4-7 Nm page 2-42
Rear fender fastener 12-36
in-lbs
1.4-4.0 Nm page 2-88
Rear inner fender mounting fasten-
ers
12-36
in-lbs
1.4-4 m page 2-62
Rear remote master cylinder reser-
voir fastener
48-72
in-lbs
11-14 Nm page 2-40
Rotor mounting fasteners, front 25-27 ft-lbs 34-37 Nm metric, Replace with new, page 2-16
Rotor mounting fasteners, rear 25-27 ft-lbs 34-37 Nm Replace with new, page 2-20
Shift lever pinch screw 48-60
in-lbs
5.4-6.8 Nm LOCTITE 272 (red), Page 2-71
Shift pedal flange head bolt 22-24 ft-lbs 30-32.5 Nm page 2-71
Shock absorber, lower 15-17 ft-lbs 20.3-23 Nm page 2-62
Shock mounting fastener, upper 48-52 ft-lbs 65-70.5 Nm page 2-66
Sidestand bracket fasteners 25-27 ft-lbs 34-37 Nm page 2-105
Sidestand pivot bolt 18-20 ft-lbs 24-27 Nm page 2-105
Sprocket cover fastener 12-36
in-lbs
1-4 Nm page 2-87
Sprocket fasteners 35-37 ft-lbs 48-50 Nm Replace with new, page 2-20
Steering stem capnut 38-42 ft-lbs 52-57 Nm page 2-55
Steering stem pinch fastener
(XB9SX)
23-25 ft-lbs 31.2-33.8 Nm LOCTITE 272, page 2-55
ITEM TORQUE NOTES
