2006 Buell Lightning: Fuel System 4-107
HOME
FUEL PUMP 4.39
GENERAL
The fuel pump is located inside the left rear portion of the fuel
tank/frame.
DRAINING FUEL TANK
1WARNING1WARNING
To prevent spray of fuel, purge system of high-pressure
fuel before supply line is disconnected. Gasoline is
extremely flammable and highly explosive, which could
result in death or serious injury. (00275a)
1. Purge the fuel supply line of high pressure gasoline.
a. See Figure 4-92. Disconnect the 4-place fuel pump
connector (1) [86]. Connector is located inside the
left rear portion of the fuel tank/frame.
b. With the motorcycle in neutral, start the engine and
allow vehicle to run.
c. When the engine stalls, press the starter button for 3
seconds to remove any remaining fuel from fuel line.
1WARNING1WARNING
Stop the engine when refueling or servicing the fuel sys-
tem. Do not smoke or allow open flame or sparks near
gasoline. Gasoline is extremely flammable and highly
explosive, which could result in death or serious injury.
(00002a)
2. Remove drain plug (4) and drain fuel into appropriate
container. Discard plug.
3. When fuel tank is empty, replace with new drain plug.
Tighten to 84-108 in-lbs (9.5-12.2 Nm).
Figure 4-92. Fuel Pump Installation
