B-14 2006 Buell Lightning: Appendix B

HOME

ELECTRICAL CONNECTORS B.4

GENERAL

The following table provides a brief description of the connec-

tors found on the Buell Lightning.

Connector numbers are listed in [brackets] in this manual.

Table B-2. Electrical Connector and Location Table

CONNECTOR COMPONENT(S) DESCRIPTION LOCATION

[10] ECM (black) 12-place Deutsch under seat

[11] ECM (gray) 12-place Deutsch under seat

[14] cam position sensor 3-place Deutsch under sprocket cover

[18] right rear turn signal 2 1-place bullet under seat

[19] left rear turn signal 2 1-place bullet under seat

[22] right hand controls 4-place Multilock behind windscreen

[24] left hand controls 4-place Multilock behind windscreen

[30] ﬂasher 5-place Amp behind windscreen

[31] right front turn signal 2 1-place bullet behind windscreen

[31] left front turn signal 2 1-place bullet behind windscreen

[33] ignition switch 4-place Augat behind windscreen

[38] headlamp connector 4-place Amp behind windscreen

[39] instrument module 20-place Multilock in front modules behind windscreen

[45] license plate lamp 2 1-place bullet under seat

[46] stator 4-place Deutsch under sprocket cover

[65] vehicle speed sensor 3-place Deutsch under sprocket cover

[77] voltage regulator 2-place Packard under sprocket cover

[83] ignition coil 3-place Packard

beneath air cleaner assembly base-

plate base

[84] front fuel injector 2-place Packard

beneath air cleaner assembly base-

plate base

[85] rear fuel injector 2-place Packard

beneath air cleaner assembly base-

plate base

[86] fuel pump 4-place Multilock left side of rear shock absorber

[88] throttle position sensor 3-place Packard right side of engine between cylinders

[89] intake air temperature sensor 2-place Amp in air cleaner assembly baseplate base

[90] engine temperature sensor 1-place bullet

beneath air cleaner assembly base-

plate base

[91A] data link 4-place Deutsch under seat, right side of vehicle

[93] tail light

2-place spade

1-place spade

(ground)

back of tail light, under seat
