2-82 2006 Buell Lightning: Chassis
HOME
MIRRORS 2.30
REMOVAL
1. See Figure 2-111. Loosen adjuster nut (2) and remove
mirror (1) from mount (3).
2. Loosen mount (3) and remove from bracket (4).
INSTALLATION
1. See Figure 2-111. Install mount (3) onto bracket (4) and
tighten to 20-22 ft-lbs (27.1-29.8 Nm).
NOTE
In a convex mirror, cars and other objects will look smaller
and farther away than they actually are. Adjust mirrors to see
a small portion of the riders shoulders in each mirror. This
helps the rider establish the relative distance of vehicles to
the rear of the motorcycle.
2. Install mirror (1) and while holding in position for rider
vision, tighten adjuster to 115-130 in-lbs (13-14.7 Nm).
Figure 2-111. Mirrors and Mounting Hardware (Typical)
1. Mirror
2. Adjuster nut
3. Mount
4. Bracket
1
1
2
3
3
4
9990
2
