2006 Buell Lightning: Chassis 2-101
HOME
WINDSCREEN 2.42
REMOVAL
NOTE
The windscreen fasteners (3) extend through the left and right
front modules (2, 5) and thread into the headlight mounting
bracket (1).
1. See Figure 2-126. Remove four windscreen
fasteners (3).
2. Remove windscreen (4).
INSTALLATION
1. See Figure 2-126. Position windscreen (4) onto left and
right front modules (2, 5).
2. Install four fasteners (3) and tighten to 10-12 in-lbs (1.1-
1.4 Nm).
Figure 2-126. Front Windscreen
b1153x2x
1. Headlight mounting bracket
2. Left front module
3. Windscreen fastener (4)
4. Windscreen
5. Right front module
2
4
5
1
3
3
