2-74 2006 Buell Lightning: Chassis
HOME
HEADLIGHT ASSEMBLY WITH GRILLE (XB9SX) 2.26
GENERAL
See Figure 2-104. The headlight grille is offered as a stan-
dard feature on the XB9SX to provide additional protection for
the headlight assemblies.
NOTE
When spreading the headlight grille during removal/installa-
tion be careful not to spread the grille too far. If this happens
simply compress the grille until it fits snugly on the headlight
assemblies.
REMOVAL/INSTALLATION
1. See Figure 2-104. Grab headlight grille on either side
and spread to remove from headlight assemblies.
2. Spread headlight grille with hands and snap back in
place over headlight assemblies.
Figure 2-104. XB9SX Headlight Grille
1. Headlight assemblies
2. Headlight grille
2
1
10728
