Buell 2006LIGHTNING MODELS User Manual

4-20 2006 Buell Lightning: Fuel System
HOME
CHECK ENGINE LAMP ON CONTINUOUSLY 4.10
GENERAL
See Figure 4-16. If the engine stop switch is set to RUN with
the engine off, and the ignition key switch is turned ON, the
check engine lamp should illuminate for four seconds.
Following the initial period of illumination, the lamp should go
off for four seconds. It may then come back on for an eight
second period (for a stored error) or remain on continuously
(current error).
DIAGNOSTICS
Diagnostic Notes
See Figure 4-19. The reference numbers correlate with the
circled numbers on the Test 4.10 flow chart.
1. See Figure 4-16. If the lamp goes off when the black
ECM connector [10] is unplugged, the BK/Y wire is not
shorted to ground.
Figure 4-16. Check Engine Lamp
Figure 4-17. Electronic Control Module, (XB12Ss)
Figure 4-18. Electronic Control Module (Typical)
9952
12150
8891
