2006 Buell Lightning: Appendix B B-15
HOME
[95] clutch switch 2-place Multilock underside of clutch lever assembly
[97] cooling fan 2-place Multilock behind rear cylinder, under seat
[120] oil pressure switch post terminal crankcase above oil filter
[121] front brake switch 2-place Multilock
underside of front master cylinder
assembly
[121] rear brake switch 2-place Multilock under seat
[122] horn spade terminals behind windscreen
[128] starter solenoid spade terminals top of starter
[131] neutral switch 1-place bullet under sprocket cover
[134] bank angle sensor 6-place Sumitomo under seat
[137] oxygen sensor 1-place Packard behind rear cylinder head
[164] Interactive exhaust circuit to ECM under seat
[161] Interactive exhaust to solenoid
under air cleaner assembly baseplate
cover
[178] Active intake system to solenoid
under air cleaner assembly baseplate
cove
[179] Active intake system to ECM under seat
Table B-2. Electrical Connector and Location Table
CONNECTOR COMPONENT(S) DESCRIPTION LOCATION
