2006 Buell Lightning: Appendix B B-3
HOME
Figure B-4. 3-Place and 6-Place Amp Multilock Connectors
– AMP
123
– AMP
123456
56 78 910
43 21
Socket terminal
Secondary lock
Socket housing
Pin housing
Pin terminal
Latch
Secondary lock
Button
Latch
Socket terminal
Secondary lock
Button
Socket housing
Pin housing
Secondary lock
Pin terminal
3-place 6-place 12-place
Secondary locks open (socket housings shown)
Stamped numbers on secondary locks indicate wire color locations
d0245x2x
