2006 Buell Lightning: Chassis 2-79
HOME
Figure 2-108. Right Front Module Fastener and Brake Line P-Clamp Fastener (Typical)
8998
Figure 2-109. Fairing Support Bracket Assembly
b1149x2x
1. Left and right front module
2. Right front module overlaps left front module
3. Right front module
4. Left front module
1
2
3
4
b1148x2x
