2006 Buell Lightning: Appendix B B-9
HOME
Figure B-13. 2-Pin, 3-pin and 4-pin Deutsch Connectors
1. Socket terminal
2. Wire seal
3. Socket housing
4. External latch
5. Internal seal
6. Locking wedge
7. Locking wedge
8. Latch cover
9. Pin housing
10. Wire seal
11. Pin terminal
SOCKET SIDE PIN SIDE
1
2
4
5
6
7
8
9
10
11
3
2-pin connector
1
2
4
3
5
6
7
8
10
11
9
3-pin connector
1
2
4
5
6
7
8
9
10
11
3
4-pin connector
d0251x3x
