4-28 2006 Buell Lightning: Fuel System
HOME
Test 4.11 (Part 3 of 3)
Continued from Test 4.11 (Part 2 of 3).
Reconnect cam position sensor connector [14]. Measure
voltage between Pin 3 and Pin 7 of Breakout Box (GY).
Voltage should alternate between 0 and 5 volts while
cranking.
Does it?
YES
Problem may be intermittent. Verify that
connectors [10], [11] and [14] are recon-
nected. Remove Breakout Box and try to
start vehicle. Will vehicle start?
With engine running, wiggle cam
position sensor and wires to iden-
tify any loose connects (engine
misfires or stalls.) Any found?
YES
Pinion gear key
failure, loose rotor
cup or other
mechanical failure.
NO
Replace cam
position sensor. See 4.31
CAM POSITION SENSOR
AND ROTOR.
NO
Repair.
YES
NO
Disconnect connector [14]. Measure resis-
tance between Terminal B and Connector
[14B] and Breakout Box (GY) Pin 3.
Is resistance greater than 1.0 ohms?
Remove cam timer
cover using 1/8 in.
drill bit. Crank
starter. Does rotor
cup rotate?
NO
Repair open
connection.
YES
Mechanical failure.
Inspect for loose
rotor cup and
sheared pinion
gear key.
NOYES
7945
7952
7952
7945
7940
Replace cam position
sensor. See 4.31
CAM POSITION SEN-
SOR AND ROTOR.
7952
To Next Page
