4-70 2006 Buell Lightning: Fuel System
HOME
Code 23/32 Test (Part 2 of 2)
NO
Continued from Code 23/32 Test (Part 1 of 2).
Check for 12 volts at Terminal 87 of the ignition
relay. Is voltage present?
YES
Ignition relay is OK. Measure resistance
between Terminal 87 of the ignition relay and
Terminal 2 (W/Y for Code 23 or GN/GY for
Code 32) wire at injector connector.
Is resistance less than 0.5 ohm?
With DVOM still
attached, perform 4.7
WIGGLE TEST to locate
intermittents. Repair
as necessary.
Find and repair
connection or
open wire.
YES NO
Check for multiple codes.
See 4.4 CHECKING FOR
TROUBLE CODES.
Clear codes and confirm proper operation with no
check engine lamp. Codes can be cleared using
DIGITAL TECHNICIAN (Part No. HD-44750).
To Next Page
