4-130 2006 Buell Lightning: Fuel System
HOME
HOSE ROUTING
Both fuel tank and canister vent hoses are routed through
notch in fan body.
NOTE
For information on vent hose routing, see D.1 HOSE AND
WIRE ROUTING.
1WARNING1WARNING
Always make sure fuel hoses are seated against the com-
ponent they connect to and that hose clamps are prop-
erly tightened and positioned on straight section of
fitting and not on the fitting barb. Failure to comply may
result in fuel leakage which could result in death or seri-
ous injury.
Figure 4-123. Emissions Hose Attachment, California
Models Only
10645
