2006 Buell Lightning: Starter 5-1
HOME
SPECIFICATIONS 5.1
TORQUE VALUES
Table 5-1. Starter Specifications
STARTER
Free speed 3000 RPM (min.) @ 11.5 V
Free current 90 Amp (max.) @ 11.5 V
Stall current 400 Amp (max.) @ 2.4 V
Stall torque 8 ft-lbs (11 Nm) (min.) @ 2.4 V
Table 5-2. Service Wear Specifications
SERVICE
WEAR LIMITS
IN. MM
Brush length (min.) 0.433 11.0
Commutator diameter
(min.)
1.141 28.981
ITEM TORQUE NOTES
Battery terminal fasteners 72-96
in-lbs
8-11 Nm page 5-19
Starter battery positive cable nut 60-85
in-lbs
7-10 Nm page 5-19
Starter mounting bolts 13-20 ft-lbs 18-27 Nm page 5-19
