7-2 2006 Buell Lightning: Electrical
HOME
TORQUE VALUES
Instruments
Turn signal indicator 1 1.12 0.08 Y0163.02A8
Check engine 1 1.12 0.08 Y0163.02A8
High beam 1 0.7 0.05 Y0162.02A8
Oil indicator 1 1.12 0.08 Y0163.02A8
Neutral 1 1.12 0.08 Y0163.02A8
Backlight
2 1.12 0.08 Y0163.02A8
1 0.7 0.05 Y0162.02A8
Low fuel Replace instrument cluster if low fuel warning lamp fails.
Table 7-7. Bulb Chart
BULB CHART
BULBS
REQUIRED
WATTS AMPS
PART
NUMBER
ITEM TORQUE NOTES
Actuator ground wire 72-96
in-lbs
8-11 Nm page 7-76
Battery (+) to starter fastener 60-85
in-lbs
7-10 Nm page 7-34
Battery terminal fasteners 72-96
in-lbs
8-11 Nm page 7-74
Clutch switch fasteners 7-10
in-lbs
0.8-1.12 Nm page 7-16
Handlebar control housing screws
(left side)
25-33
in-lbs
3-4 Nm page 7-53
Handlebar control housing screws
(right side)
25-33
in-lbs
3-4 Nm Longer screw on bottom, page 7-52
Horn fastener 72-96
in-lbs
8-11 Nm page 7-62
Ignition switch body fastener 12-36
in-lbs
1.4-4.0 Nm page 7-8
Ignition switch fastener 18-20 ft-lbs 24.4-27.1 Nm LOCTITE (red) 272, page 7-9
Instrument module fastener 12-36
in-lbs
1.4-4.0 Nm page 7-56
Interactive exhaust actuator fasten-
ers
36-40
in-lbs
4.0-4.5 Nm page 7-76
Main battery ground 48-72
in-lbs
5.4-8.1 Nm page 7-34
Neutral indicator switch 36-60
in-lbs
4-6.8 Nm LOCTITE 243 (blue), page 7-64
Retainer plate fasteners 56
in-lbs
6.3 Nm page 7-31
Rotor mounting fasteners 90-110
in-lbs
10-12 Nm LOCTITE THREADLOCKER 243, page 7-31
Spark plugs 11-18 ft-lbs 15-24 Nm page 7-1
Stator TORX mounting screws 30-40
in-lbs
3-4 Nm
T-27 TORX with retaining compound, replace
with new after each removal, page 7-31
Tail lamp lens and tail light 6-7
in-lbs
0.7-0.8 Nm page 7-45
Turn signal fastener (rear) 25-28
in-lbs
2.8-3.2 Nm page 7-49
Turn signal fasteners (front) 25-28
in-lbs
2.8-3.2 Nm page 7-49
Turn signal flasher fastener 30-40
in-lbs
3-4 Nm page 7-50
Voltage regulator mounting screws 36-60
in-lbs
4.1-6.8 Nm Use new fasteners, page 7-32
