Speedometer Test: Chart 1
ODOMETER, TRIP ODOMETER AND RESET SWITCH TESTING
NO
Replace instrument
module.
YES
Press trip mode switch.
Does display toggle
between trip and
odometer modes?
Turn ignition ON. Does odometer display
consist of correct numbers?
YES
Verify trip display
consists of correct
numbers. Are correct
numbers displayed?
NOYES
6020
6020
STOP
NO
6020
Press reset for 5 sec-
onds. Does trip odome-
ter reset to zero?
NO
6020
Replace instrument
module.
Replace instrument
module.
Replace instrument
module.
Go to
Speedometer Test:
Chart 2A.
