1-8 2006 Buell Lightning: Maintenance
HOME
Clutch and throttle cables Lubricant
LUBIT-8 TUFOIL
®
CHAIN AND CABLE LUBE
(Part No. HD-94968-85TV)
Handlebar clamp screw torque 60-84
in-lbs
(6.8-9.5 Nm)
Handlebar switch housing screw torque 25-33
in-lbs
(3-4 Nm)
Spark plugs Type 10R12A
Gap 0.035 in. (0.9 mm)
Torque 12-18 ft-lbs (16-24 Nm)
Engine idle speed Idle speed 1050-1150 RPM
Front fork oil Type: All models except XB12Scg HYDRAULIC FORK OIL (TYPE E)
Part No. 99884-80
4.21 in. (107 mm) from the top of the fork tube
Battery Lubricant ELECTRICAL CONTACT LUBRICANT
Part No. 99861-02 (1 oz.)
Battery terminal torque 72-96
in-lbs
(8-11 Nm)
Table 1-2. Quick Reference Maintenance Chart
ITEM SERVICED SPECIFICATION DATA
